LifePo4 Li-ion 72V 20S 40A BMS
- Over Discharge Protection
- Over Charge Protection
- Over Current Protection
- Short Circuit Protection
- Common Port, with Balanced
- Dropped Line Protection
- 16S 18S 20S, 30A 40A 50A 100A 150A 200A available
- Customized S and A support.
Additional information
Product Details:
20S 40A 72V Li-ion BMS
| Details | Spec | |
| Voltage | Charge Voltage | 84V |
| Common Port | Yes | |
| Overcharge Protection | Overcharge Detection Voltage | 4.25V ± 0.05V |
| Overcharge Release Voltage | 4.15V ± 0.08V | |
| Overcharge Protection Delay time | 800mS | |
| Over Discharge Protection | Over Discharge Detection Voltage | 2.8V ± 0.1V |
| Over Discharge Release Voltage | 3.0V ± 0.1V | |
| Over Discharge Delay time | 2000mS | |
| Over Current Protection | Continuous discharging current | 40A |
| Discharge Over Current Protection | 120A | |
| Charge Current | 20A | |
| Charge Current Protection | 26 +10A | |
| Over Current Protection Release Condition | Loading disconnection | |
| Short Circuit Protection | Short Circuit Protection Conditions | Short circuit of external load |
| Short Circuit Protection Release Condition | Charging recovery or loading disconnection | |
| Balance | Balance Detection Voltage | ≥4.18V |
| Balance Release Voltage | <4.18V | |
| Balance Current | 20-30mA | |
| Self-consumption of power | Working Consumption Power | <50uA |
| Temperature Protection | Operating Temperature Range | -20 / 70℃ |
| Discharge Temperature Protection | 75℃ ± 5℃ | |
| Discharge Release Temperature | 53℃ |
